Ka inoa inoa:PNEK
E hoʻohana: ʻAiʻai mahiʻai/Mariculture/Waʻau ʻauʻau/Ka hana ʻenehana
Kala: Nui nā kala i loaʻa no ke koho
Mea: UPVC
Mahana o Media: Kiʻekiʻe wela, haʻahaʻa wela, Medium wela, maʻamau wela
Ke ola huahana::> 500,000 manawa wehe a pani
Hōʻike huahana
Hiki i kā mākou hui ke kū'ē i ka corrosion maikaʻi loa, no laila hiki ke hoʻonui maikaʻiʻia kona ola lawelawe, aʻo ka huahana pono'ī he mea maʻalahi a maʻalahi, me ka ikaika kiʻekiʻe a me ka liʻiliʻi liʻiliʻi, no laila mahalo nuiʻia e nā mea kūʻai. Hoʻohana nui ʻia lākou i nā hale ʻoihana a me nā hale kīwila, e komo pū me ka wai wai i loko a i waho.
nā papahana paipu wai, nā kūlana kemika corrosion a hiki ke hoʻohana ʻia no ka ʻōnaehana irrigation mahiʻai.
Ma waho aʻe, kūpono lākou no ka paipu hoʻoheheʻe a me ka pipeline wai, a me nā mea ʻē aʻe. 100% leak test e hōʻoia i ka maikaʻi o nā huahana āu e kiʻi ai. E nānā ʻia nā huahana maʻamau i ka wā o ka hana ʻana e hōʻoia i ka loaʻa ʻana o nā huahana i ka pae honua.
Ke hoʻomau nei ka piʻi ʻana o ka nui o nā paipu plastik i ka wai wela a me ka wai anuanu a me nā noi ʻenehana paipu ʻenehana, ʻoi aku ka nui o ka mana o ka maikaʻi o nā kiwi plastik i nā ʻōnaehana paipu plastik.
Nā mea maikaʻi o ka huahana
1, Ke kaumaha māmā a me ka ikaika kiʻekiʻe
2. ʻAʻohe leo haʻalulu ke hoʻohana ʻia
3. E maʻalahi e wehe a pani
4. He mea maʻalahi ka hoʻokomoʻana i ka valve ball compact
5. Haʻahaʻa leakage rate, 100% ho'āʻo ma mua packing
6. He liʻiliʻi ke kūpaʻa wai
7. Hoʻopaʻa i nā mea o ka pahu kinipōpō: ABS, mea kino: PVC
8. Alkali a me kaʻakika kū'ē
9. kala palupalu a me ka hoʻolālā execllent
10. Pili kaiapuni, non-toxic
11. Hoʻohana nui ʻia i ke ola o kēlā me kēia lā: ʻO ke kūkulu ʻana, ka irrigation mahiʻai, ka ʻoihana, ka māla, ka wai ʻauʻau ...
12. Hāʻawi ʻia kēia mau pōlele pōlele i nā nui mai 20mm a 110mm (mai 1/2 '' a 4 '')
13. Loaʻa ke kala: ʻOmaomao, hina, keʻokeʻo, ʻeleʻele, uliuli
14. Palapala hōʻoia: ISO 9001, ho'āʻo china
Kaao a me ka palapala honua
Mea ʻāpana
kikoo o ka mea
| ʻAʻOLE. | Māhele | Mea waiwai | QTY |
| 1 | KINO | UPVC,CPVC | 1 |
| 2 | STEM O-Ring | EPDM,FPM(NBR) | 1 |
| 3 | STEM | UPVC,CPVC | 1 |
| 4 | BOLA | UPVC,CPVC | 1 |
| 5 | SIALA NOHO | TPE,TPVC,TPO | 2 |
| 6 | KAPA | PVC, ABS | 1 |
| 7 | LIMA | PVC, ABS | 1 |
| 8 | KAUKA | SS304, HAAWINA | 1 |
Pākaukau hoʻohālikelike hoʻohālikelike ʻano nui
| NANA | Unite | |||||||||||
| HOIKE | DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | ||
| NUI | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" | 4" | ʻīniha | ||
| thd./in | NPT | 14 | 14 | 11.5 | 11.5 | 11.5 | 11.5 | 8 | 8 | 8 | mm | |
| BSPT | 14 | 14 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | mm | ||
| JIS | I | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | mm | |
| d1 | 22.3 | 26.3 | 32.33 | 38.43 | 48.46 | 60.56 | 76.6 | 89.6 | 114.7 | mm | ||
| d2 | 21.7 | 25.7 | 31.67 | 37.57 | 47.54 | 59.44 | 75.87 | 88.83 | 113.98 | mm | ||
| ANSI | I | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | mm | |
| d1 | 21.54 | 26.87 | 33.65 | 42.42 | 48.56 | 60.63 | 73.38 | 89.31 | 114.76 | mm | ||
| d2 | 21.23 | 26.57 | 33.27 | 42.04 | 48.11 | 60.17 | 72.85 | 88.7 | 114.07 | mm | ||
| DIN | I | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | mm | |
| d1 | 20.3 | 25.3 | 32.3 | 40.3 | 50.3 | 63.3 | 75.3 | 90.3 | 110.4 | mm | ||
| d2 | 20 | 25 | 32 | 40 | 50 | 63 | 75 | 90 | 110 | mm | ||
| d | 15 | 19 | 24 | 30 | 34 | 45 | 55 | 70 | 85 | mm | ||
| H | 37 | 55 | 66 | 73 | 81 | 91 | 99 | 121 | 134 | mm | ||
| A | 68 | 80 | 94 | 100 | 110 | 136 | 170 | 210 | 236 | mm | ||
| L | 77 | 91 | 103 | 111 | 123 | 146 | 178 | 210 | 255 | mm | ||
| D | 30 | 35.5 | 43 | 52 | 62 | 75 | 91 | 106 | 130 | mm | ||
